Product Features :
- Transmits HDMI signal up to 40M distance over single Cat5e and up to 60M over single Cat6 Cable
- HDMI 1.3 & 3D Support
- The network line conforms to the standard of IEEE-568B
- Support video resolution up to 1080P@60Hz
- Support audio format: DTS-HD / Dolby-true HD / LPCM7.1 / DTS / Dolby-AC3 /DSD
- Support POC / IR (Optional)
Specification :
- Video Standard : HDMI 1.3; HDCP 1.2
- Maximum pixel clock : 165MHz
- Maximum data rate : 6.75Gps
- Resolution : 1920 x 1080@60Hz, 3D
- Connector : HDMI-A
- Impedance : 100Ω
- Transmission distance : CAT6 --- 60M
- Power Supply : DC 5V / 1A
- Power Consumption : MAX 3W
- Operating Temperature : -5℃ ~ + 70℃
- Operating Humidity : 5% ~ 90%
- Dimension : 81mm x 45mm x 23mm
IR (Optional) : Interface 3.5mm earphone jack. Frequency : 38KHz, Unidirectional transmission.
