INTRODUCTION
NSE-MG2 is a professional HD/3G-HDMI H.264 video encoder. Small size and ultra-low consumption design ! NSE-MG2 comes in 1.485G HD-HDMI, 3G-HDMI input, and HDMI looping out. Input HDMI signal through prceding image processor for image enhancement, then encoding by SOC processor for creating H.264 video encode featured with high performance and low bit rate.
NSE-MG2 supports unbind audio from HDMI Signal, also input audio from Analog Line-in for AAC (MPEG4-Audio) stereo audio encoding or G.711 audio encoding.
PRODUCT FEATURES
l High Integration, portable, low consumption, high performance;
l Low bit rate assuring nice image and quality audio;
l 4G-LTE USB dongle supported;
l Built-in WIFI (dual band : 2.4G/5.8G), IEEE 802.11 a/b/g/n;
l Powerful streaming media protocols supported and full service function;
l Simultaneously support 20 ~ 50 Concurrent users access;
l Easy operation and professional quality;
l Supported Global live video platform : YouTube, UStream, Twitch and so on;
l Supported streaming media server platform/CDN system (tested): Wowza, FMS, REDS, SRS, etc.,
l Ethernet & External USB 4G-LTD Dongle Supported;
l Local storage and recording based on Micro SD/TF card and/or USB storag;
l Support image rotation, cutting, gray scale and other special image processing;
l Support character / image overlay;
SPECIFICATIONS
| INTERFACE | Video Input | HDMI * 1 |
| Video Looping Input | HDMI * 1 | |
| Analog Audio Input | 3.5mm * 1 | |
| Analog Audio Output | 3.5mm * 1 | |
| Wired Network | RJ-45 10/100M Ethernet * 1 | |
| Wi-Fi | 2.4G/5.0G Dual band Wi-Fi network with 2 External Antenna |
|
| USB | USB 2.0 Type-A * 1 USB 2.0 Mini-USB * 1 |
|
| Micro SD | Micro SD/TF Card slot * 1 | |
| Signal & formats | HDMI signal standard | 0.8vp-p |
| HDMI impedance | 75 Ohm | |
| HDMI coupling way | AC | |
| HDMI signal formats | HD-HDMI (1.485Gbps) 3G-HDMI (2.97Gbps) |
|
| Supported video formats |
This email address is being protected from spambots. You need JavaScript enabled to view it./24/25/29.97/30 1080p50/59.94/60 1080i50/59.94/60 720p23.98/24/25/29.97/30 720p50/59.94/60 |
|
| Audio | HDMI unbind audio (stereo) Analog Line-in/Line-out (stereo) |
|
| Encoding |
Video encoding | H.264/AVCHigh profile (up to level 5.1), compatible with main profile and Baseline |
| Audio encoding | AAC/MPEG4-Audio, G.711 (u-Law/a-Law) |
|
| Encoding delay | ≤ 67ms | |
| Video encoding | 256Kbps ~ 25Mbps adjustable | |
| Audio encoding resolution |
32Kbps ~ 512Kbps : AAC 64Kbps : G.711 |
|
| Network support |
Wired/Ethernet | Built-in support |
| Wi-Fi | Built-in, IEEE 802.11 a/b/g/n 2.4G/5.8G dual band |
|
| 4G-LTE | Support through USB extend dongle |
|
| Transmission protocols and Management protocols | Transmission protocols |
RTP/RTSP (compatible RTP over RTSP, RTSP HTTP Tunnel and RTSP Multicast) RTMP pushing, RTMP service, TS over UDP, HLS |
| Control/Management Protocol |
Onvif 1.1/2.0 | |
| Management protocol | HTTP | |
| Working environment, Size & Accessories | Power | DC 12V 1A |
| Operating temperature | - 20°C ~ 80°C | |
| Operating temperature | 20 ~ 90% RH (un condensation) | |
| Power consumption | 4W Max (exclude 4G-LTE USB Dongle) |
|
| Weight | 220g | |
| Wi-Fi antenna | 2*5db 2.4G / 5.8G Dual-band | |
| Power adapter | External DC 12V 1A adapter |
